ADDITIONAL PARTS LIST (Colors and styles may vary)
Symbols and Numbers
-1-
Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
3 1-Snap Wire 6SC30001 1 10µF Capacitor 6SC30032
3 2-Snap Wire 6SC30002 1 100µF Capacitor 6SC30033
1 3-Snap Wire 6SC30003 1 470µF Capacitor 6SC30034
1 4-Snap Wire 6SC30004 1 1kΩ Resistor 6SC30041
1 7-Snap Wire 6SC30007 1 5.1kΩ Resistor 6SC30042
1
Battery Holder - uses
2 1.5V type AA (not Included)
6SC30019 1 10kΩ Resistor 6SC30043
1 Antenna Coil 6SC30025 1 100kΩ Resistor 6SC30044
1
Green Light Emitting
Diode (LED)
6SC30026 1
High Frequency
Integrated Circuit
6SC30045
1
6V Lamp Socket
6V Bulb (6.2V, 0.5A)
Type 425 or similar
6SC30027
6SC30027B
1 PNP Transistor 6SC30051
1 Microphone 6SC30028 1 NPN Transistor 6SC30052
1
Power Amplifier
Integrated Circuit
6SC30029 1 Adjustable Resistor 6SC30053
1 0.02µF Capacitor 6SC30030 1 Variable Capacitor 6SC30054
1 0.1µF Capacitor 6SC30031
D2
A1
B1
7
4
3
2
1
L2
X1
U4
C1
C2
U5
R5
R4
R3
R2
C5
C4
C3
Q1
Q2
RV
CV
