Elenco Electronics ST-3030 - Page 11

Resistance
Overload Protection: 250VDC or AC rms
Capacitance
Overload Protection: 250VDC or AC rms
Diode and Audible Continuity Test
Overload Protection: 250VDC or AC rms
Frequency
Sensitivity: sine wave 0.6V rms (10MHz: 1.5V rms)
Overload Protection: 250VDC or AC rms
-11-
Range Accuracy Resolution
400Ω
±(1.0% + 2)
0.1Ω
4kΩ 1Ω
40kΩ 10Ω
400kΩ 100Ω
4MΩ 1kΩ
40MΩ ±(2.0% + 3) 10kΩ
Range Accuracy Resolution
40nF
±(3.0% + 10)
10pF
400nF
±(2.5% + 5)
100pF
4μF 1nF
40μF
±(5.0% + 10)
10nF
100μF 100nF
Range Description Test Condition
Display read approximately
forward voltage of diode
Forward DC current approx. 0.4mA
Reversed DC voltage approx. 1.5V
Built-in buzzer sounds if
resistance is less than 120Ω
Open circuit voltage approx. 0.5V

Range Accuracy Resolution
10Hz
±(0.1% + 5)
0.01Hz
100Hz 0.1Hz
1kHz 1Hz
10kHz 10Hz
100kHz 100Hz
1MHz 1kHz
10MHz 10kHz
