OUT MOTOR
SINGLE PHASE:
• L/S - Motor phase
• N/R - Motor idle
• AVV - Start with on board capacitor
THREE PHASE:
• T1 (contactor) - Motor phase U
• T2 (contactor) - Motor phase V
• T3 (contactor) - Motor phase W
Earthing.
