9 5041 2E22
2.1
Unpacking
We appreciate that you have decided to purchase our Products and we would
like to ask you to begin the installation by checking your delivery against the
Packing List. Please make sure to check the box for external damages before
opening. If you find external damages, which have also led to damages to the
Flow Monitor inside, you should contact the forwarder/shipper to claim repla-
cement (or the cost of replacement). Check the Monitors’ identification tag
against your purchase order to make sure you have got the right parts with
the right specifications.
All Monitors are individually packed in a box. The box is made from recycled
environmentally friendly material and we kindly ask you to deal with the
waste material in a way that will have as little impact on the environment as
possible.
2.2
Procedures before Installation
Note!!! Before any installation or maintenance work, disconnect all
electrical power!
Please check that you are going to mount the Monitor at the lowest point in the
piping system if you are measuring liquids and at the highest point if you are
measuring gases. Also check if the planned flow direction in the system mat-
ches the one indicated on the Monitor. There is a red flow direction arrow on
the outside of the pipe section (not the Stainless Steel models which have a
marking engraved on the side). If you find this to mismatch, we refer to sec-
tion 3.4 ”Change of Flow Direction”, to adjust the internal flow director in or-
der to match the desired flow direction. Change of the flow direction on the
Stainless Steel Pipe Sections (FSS/GSS) is not possible in the field without
ordering a new Pipe Section and we kindly ask you to contact your local re-
presentative or Eletta Flow AB, Sweden for help.
Check that the pipe section has the right threads or the right flange standard to
match your piping or counter flange.
If you are using the separate/remote execution i.e. Pipe Section and Control
Unit installed in different locations, please check the plastic hoses for any da-
mages or holes that can prevent proper function. The plastic hoses
To Next Page
