7.1 Replacement Pump Parts - TS05
Fig
#
Description Qty Part No.
1 Crank case 1 00 02 2560 0
2 Stud M12 x 45 4 00 05 1456 0
Stud M12 x 54 4 00 05 1455 0
3 Gasket, Free end cover 1 00 04 2550 0
4 Free end cover 1 00 03 1770 0
5 Spring washer M8 10 00 09 96 108
6 Bolt Hex. M8x25 10 00 09 06 116
7 Nipple hex. ½” BSP x ½” BSP 1 00 04 1843 A
8 Elbow ½” BSP 1 00 09 72 053
9 Pipe, breather 1 02 04 9285 0
10 Reducer ½” BSP x 1” BSP 1 02 04 9246 0
11 Breather assembly 1 A02 0201
12 Rink packing, 17x22x2 1 00 05 2186 0
13 Oil Drain plug, 3/8” BSP 1 A02 0033
14 ‘O’ Ring, OLI 1 00 05 2655 0
15 Oil Level Indicator 1 00 05 1344 0
16
Conn. rod & Combined Crank
shaft assy.
1 A02 0231
17 Bearing 6305 1 00 09 03 346
18 Bearing 6307 1 00 09 03 352
19 Gasket, Fly end cover 1 00 04 2551 0
20 Oil seal, B32x54x7 1 00 04 2034 0
21 Fly end cover 1 02 03 5039 0
22 Piston, dia 90 1 00 32 0318 0
23 Circlip, B 18 2 00 09 17 218
24 Gudgeon pin, Dia 18 1 00 34 0757 0
25
Ring, slotted oil control, Dia
90
2 00 33 0478 0
26
Ring, stepped compression,
Dia 90
1 00 33 0477 0
27
Ring, Taper plain compres-
sion, Dia 90
1 00 33 0476 0
Gasket, C/Case to Cylinder,
0.75
1 00 04 1002 A
28
Gasket, C/Case to Cylinder,
0.4
1 00 04 1002 B
Gasket, C/Case to Cylinder,
0.25
1 00 04 1002 C
Fig
#
Description Qty Part No.
29 Cylinder, dia 90 1 02 03 5012 0
30 Spring washer M12 8 00 09 96 112
31 Nut, Hex. M12 8 00 09 48 012
Stud, M12 x 86 3 00 04 7004 0
32
Stud, M12 x 96 1 00 05 1450 0
33 Valve finger 4 00 03 3097 0
34 Gasket, Cyl. To Valve flat 1 06 04 0013 A
35 Valve Flat 1 00 33 0479 0
36 Gasket, Valve flat to Head 1 06 04 0012 A
37 Centring Bush 4 00 04 2660 0
38 Head, dia 90 Cyl. 1 02 03 6001 0
39 Spring washer M12 8 00 09 96 112
40 Nut, Hex. M12 8 00 09 48 012
41 Nipple, Pipe 1 ¼” BSP 1 00 04 3217A
42 Piston dia 50 1 00 02 1357 0
43 Circlip B 12 2 00 09 17 212
44 Gudgeon pin, Dia 12 1 00 05 1431 0
45
Ring, slotted oil control,
Dia 50
2 00 04 1683 A
46
Ring, stepped compres-
sion, Dia 50
1 00 04 1590 A
47
Ring, Taper plain com-
pression, Dia 50
1 00 04 1589 A
48
Gasket, C/Case to Cylin-
der, 0.25
1 00 04 1004 A
Gasket, C/Case to Cylin-
der, 0.4
1 00 04 1004 B
Gasket, C/Case to Cylin-
der, 0.75
1 00 04 1004 C
49 Cylinder, dia 50 1 00 02 1004 0
50
Stud, M12 x 60 3 00 05 2013 0
Stud, M12 x 70 1 00 05 1883 0
51 Valve finger 2 00 03 3094 0
52 Gasket, Cyl. To Valve flat 1 00 04 1150 A
53 Valve Flat 1 00 03 1005 0
54 Gasket, Valve flat to Head 1 00 04 1151 A
55 Head, dia 50 Cyl. 1 00 02 1993 0
56 Nut, Connecting 2 00 05 1038 A
57 Connecting Piece, ¾” BSP 1 02 04 8483 0
58 Ring, Packing 2 00 05 2191 0
59 Inter cooler 1 00 33 0525 0
60 Connecting Piece, 1” BSP 1 00 04 1204 A
61 Safety valve assembly, 1 00 04 1318 0
62 Ring Packing 1 00 05 2184 0
63 Adapter, ¾” x 1” BSP 1 00 04 1017 B
64 Direction Indicator 1 00 05 1010 0
65 Rivet 6 00 04 6454 A
66 Name plate, RAC Unit 1 02 03 5180 F
