TS Series
4.0 Initial Startup
Check for correct direction of rotation of compressor by momentarily turning the Off-On switch to the
“On” position and observing rotation.
WARNING:
DO NOT RUN THE COMPRESSOR BACKWARDS!
Rotation direction arrows are located on the belt guard (rotation is clockwise, facing the compressor
pulley). Correct the rotation, if required, by switching the motor leads at the starter.
Start compressor by turning the “Off-On” switch to the “On” position. Allow compressor to operate for
a short time (15 to 30 seconds) and check for any unusual noises or vibrations.
If everything appears normal, allow compressor to run in the “On” mode until pressure builds in the
air receiver. The compressor should stop when the pressure reading reaches 125 psig. Check for
any leaks in the piping. Repair leaks, if needed.
5.0 Maintenance
Frequency Maintenance Required
Daily or before
compressor starting
a) Check oil level
b) Drain condensate from air receiver
c) Check belt tension
150 Hours or 10 Days
a) Relieve moisture and dirt from air receiver
b) Carry out first oil change
250 Hours or 20 Days
a) Check for unusual noise or vibration
b) Check bolts for tightness
c) Check for leaks
d) Check pressure settings
e) Check inlet air filter
a) Change Oil
500 Hours or 1 Month
b) Clean breather valve
c) Tighten all wires
d) Clean air filter element
