Elite Screens Elite ezFrame Series User Manual

Push
Push
( fig.2)
Insert the exposed ends of the joint connectors
into the short (vertical) frame and align the four
corners so that they meet at perfect right angles
4. Join all four frame parts together following the steps showed below. (fig.2)
5. After making sure that all four corners join at right angles to form a perfect rectangle, fasten the four
angles together by using the (x8) joint screws included. (see fig.3)
(3)
Screw
( fig.3)

Elite Screens Elite ezFrame Series Specifications

General

Brand	Elite Screens
Model	Elite ezFrame Series
Category	Projection Screen
Language	English
