GLASS LID ASSEMBLY
**Your Pressure Cooker is equipped with a
Tempered Glass Lid (21) that can be used with
the SLOW COOK function . Please do not use
this Glass Lid (21) with any other functions on
this Pressure Cooker.
Assembly of the Knob on the Glass Lid will
require a Phillips Screwdriver (not included).
Follow the diagram on the left to assemble the
knob on the Glass Lid (21).
1. Handle + 2. Handle Base (Pre-assembled)
3. Glass Lid Body
4. Silicon Gasket
5. Gasket
6. M4 Screw
PRESSURE COOKER LID MARKINGS
Please note the "OPEN" and
"CLOSE" markings on the Upper
Ring (9) of the pressure cooker
body (13) and the“ ”on the rim
of the Lid (2). To properly close
and secure the pressure cooker Lid
(2), always line up the "CLOSE"
marking on the Upper Ring (9) and
the “ ”on the rim of the Lid (2).
(Figure 1)
