Elitech ECS-10HT1 User Manual

Download the copy card
pressing the keys for 1s
Success of “do” 、
Failure of “Er”
To display the Evaporator
temperature
Press the response
Start manual defrost
pressing the keys for 2s
light
HOW TO SEE THE SET POINT :
1) Push and immediately release the SET key, the set point will be showed and the “ ”LED
starts lighting ;
2) Push and immediately release the SET key or wait about 15s to return to normal visualisation.
HOW TO CHANGE THE SET POINT :
1) Push the SET key for more than 2 seconds to change the set point value ;
2) The value of the set point will be displayed and the “set ”LED starts lighting ;
3) To change the Set value press the ▲or ▼ within 15s ;
4) To memorise the new set point value push the SET key again or wait 15s.
HOW TO CHANGE A PARAMETER VALUE :
To change the parameter’s value operate as follows:（first level Pr1）
1）Enter the Programming mode by pressing the SET+ ▼keys for 3s , the “set” LED starts to light ;
2）Select the required parameter. Press the SET key to display its value ;
3）Use▲ or ▼to change its value ;
4）Press SET to store the new value and move to the following parameter ;
5）To exit : Press SET+▲ or wait 15s without pressing a key .
HIDDEN MENU（the second level Pr2）
(The hidden menu includes all the parameters of the instrument (Pr1 and Pr2))
1) Enter the Programming mode by pressing the SET+▼ keys for 3s the” set “LED starts to light ;
2) Then push again the SET+▼ keys for more than 7s. The L2 label will be displayed immediately
followed from the Hy parameter ;
3) Select the required parameter ;
4) Press the SET key to display its value ;
5) Use ▲or ▼to change its value ;
6) Press SET to store the new value and move to the following parameter ;
7) To exit: Press SET+▲ or wait 15s without pressing a key.
NOTE: If none parameter is present in L1, after 3s the “nP” message is displayed. Keep the keys pushed
till the L2 message is displayed.
HOW TO MOVE A PARAMETER FROM THE HIDDEN MENU TO THE FIRST LEVEL AND
VICEVERSA.
Each parameter present in the HIDDEN MENU can be removed or put into “THE FIRST LEVEL”
(user level) by pressing SET+ ▼.
In HIDDEN MENU when a parameter is present in First Level the decimal point is on.
TO LOCK/ UNLOCK THE KEYBOARD
