DIAGNOSTICS
Alarms are always indicated by the alarm icon , the buzzer and the relay (if setting).
To switch off the buzzer, press and release any key; the corresponding icon will continue to flash.
N.B.: If alarm exclusion times have been set (see ‘AL’ folder in the parameters table) the alarm will not be signalled.
ALARMs
Label Fault Cause Effects Remedy
E1
Probe1 faulty
(ambient)
measured values are outside
operating range
Probe faulty/short-circuited/open
Display label E1
Alarm icon permanently on
Relay activation (if setting)
Disable max/min alarm controller
Compressor operation based on
parameters On1/2 and OF1/2
check probe type (H00)
check probe wiring
replace probe
AH1/2
Alarm for HIGH
value (Probe1)
value read by Pb1 > HA1/2 after
time of tAO.
(see ‘MAX/MIN TEMP. ALARMS’)
Recording of label AH1/2 in folder AL
Relay activation (if setting)
No effect on regulation
Wait until value read by Pb1
returns below HA1/2.
AL1/2
Alarm for LOW
value (Probe1)
value read by Pb1 < LA1/2 after
time of tAO.
(see ‘MAX/MIN TEMP. ALARMS’)
Recording of label AL1/2 in folder AL
Relay activation (if setting)
No effect on regulation
Wait until value read by Pb1
returns above LA1/2.
EA External alarm
Digital input activated
(H11 = ±5)
Recording of label EA in folder AL
Alarm icon permanently on
Relay activation (if setting)
Regulation locked
Check and remove the external
cause which triggered the alarm
on the D.I.
