PAR. DESCRIPTION
RANGE DEFAULT VALUE LEVEL U.M.
SEt Set point with range falling between the minimum
LSE set point and the maximum HSE set point.
The value of the set point is in the machine status
menu
LSE...HSE 0.0 °C/°F
diF The compressor stops when it reaches the set
point value, and restarts at a value corresponding
to the set point plus the value of the differential It
must not be 0
0.1...30.0 2.0 1-2 °C/°F
HSE Maximum set point value
LSE...302 50.0
1-2 °C/°F
LSE Minimum set point value
-55.0...HSE -50.0 1-2 °C/°F
OSP Offset point. Value to be added to set point if
reduced set point is activated (economy function).
-30.0...30.0 0 2 °C/°F
Cit Minimum compressor ON time. Minimum time for
activating a compressor before deactivation Not
active if=0
0...250 0 2 min
CAt Maximum compressor ON time. Maximum time for
activating a compressor before deactivation Not
active if=0
0...250 0 2 min
Ont (1) Compressor activation time if probe is faulty. If set
to 1 with OFt=0 the compressor always remains on
whereas if Oft>0 it operates in duty cycle mode
0...250 0 1-2 min
OFt (1) Compressor shut-down time if probe is faulty. If set
to 1 with Ont=0 the compressor always remains off
whereas if Oft>0 it operates in duty cycle mode
0...250 1 1-2 min
dOn Delay in activating compressor relay after start-up
0...250 0 1-2 sec
dOF Delay after shut-down; between compressor relay
shut-down and subsequent start-up the specified
time must elapse.
0...250 0 1-2 min
dbi Delay between switch-ons; the specified time must
elapse between two subsequent switch-ons
0...250 0 1-2 min
OdO Delay in enabling outputs after start-up of instru-
ment or after a power failure.
Not active if=0
0...250 0 1-2 min
dty Defrost type:
0 = Electrical or Off Cycle defrost
(Compressor OFF during Defrost);
1 = Reverse cycle defrost
(hot gas - Compressor On during Defrost);
2 = ’Free’ : Independent defrost (compressor cycles ON/OFF according to temperature during defrost)
0/1/2 0 1-2 flag
dit Period of time elapsing between the start of two
defrosts 0=function disabled
0...250 6 1-2 hours
dt1 Unit of measurement for defrost times (par. dit)
0=”dit” expressed in hours
1=”dit” expressed in minutes
2=”dit” expressed in seconds
0/1/2 0 2 flag
NOTE: At level 1 the folders will only display all the level 1 parameters. At level 2 the folders will only display all the
level 2 parameters. The level marked 1-2 allows the parameter to be displayed at both levels.
Defrosting controller-deF label Compressor controller-CP label
dt2 Unit of measurement for duration of defrosting
(dEt parameter)
0= “dEt” parameter expressed in hours
1= “dEt” parameter expressed in minutes
2= “dEt” parameter expressed in seconds
0/1/2 1 2 flag
dCt Selection of defrosting time count mode.
0=compressor operating hours DIGIFROST®
method). Defrosting active only if compressor is
on.
1 = equipment operating hours; defrost counting is
always active when the machine is on
2=compressor stop Each time the compressor
stops a defrosting cycle is performed according to
par. dtY
3=con RTC. Defrosting at times set by dE1...dE8,
F1...F8 parameters.
0/1/2/3 1 1-2 flag
dOH Delay between start of first defrosting operation
and start-up of instrument.
1-2 min
dEt Defrosting time-out; determines maximum dura-
tion of defrosting.
1-2 min
dSt End of defrost temperature (determined by evapo-
rator probe)
-50.0...150 8.0
1-2 °C/°F
0...59 0
1...250 30
dE2 Defrost time-out on 2nd evaporator
1...250 30
1-2 min/sec
dS2 End of defrost temperature on 2nd evaporator
-50.0...150 8.0
1-2 °C/°F
