ID 985/S/E/CK - ID985/E LX 8/14
PAR. DESCRIPTION
RANGE DEFAULT VALUE* LEVEL** U.M.
OAO High and low temperature alarm delay after dis-
abling digital input (door closed)
0...10 0 2 hours
Alarms-AL label
tdO Time out after alarm signal when disabling digital
input (door open)
0...250 0 2 min
tAO (5) Temperature alarm delay time
0...250
0
1-2 min
dAt Alarm for defrosting ended due to time out.
n=alarm not active
y=alarm active
n/y n 2 flag
rLO Controllers disabled by external alarm
0=no resources are disabled
1=disables compressor and defrosting
2=disables compressor, defrosting and fans
0/1/2 0 2 num
AOP Polarity of alarm output:
0 = alarm active and output disabled;
1 = alarm active and output enabled
0/1
1 2 flag
PbA Configuration of temperature alarm on probe 1
and/or 3:
0=on probe 1 (thermostat control)
1=on probe 3 (display)
2=on probe 1 and 3 (thermostat control and display)
3=on probe 1 and 3 (thermostat control and display)
on external threshold
0/1/2/3 0
2
num
SA3 Probe 3 alarm set point
-50.0...150.0 50 2 °C/°F
dA3 Probe 3 alarm differential
-30.0...30.0 2.0 2 °C/°F
Light & digital inputs
Lit Label
dSd Light relay enable from door switch.
n = door open, light does not turn on;
y = door open, light turns on (if it was off)
n/y y 2 flag
dLt Light relay disabling delay after closing door if
“dSd”=y
0...31 0 2 min
OFL Light relay disabled even if disabling delay
“dLt” is active
n/y n 2 flag
dAd Delay in enabling digital input
0...255 0 2 min
dOd Digital input switches off loads
n/y n 2 flag
Att Determines if “LAL” and “HAL” are expressed as
absolute values or as a differential related to the
set point
0=absolute value
1=value related to set point
0/1 0 2 flag
AFd Alarm differential
1.0...50.0 2.0 1-2 °C/°F
HAL (4) Maximum alarm. Temperature limit (whose
absolute or relative value status is regulated by
“Att”) above which the alarm is activated.
LAL...150.0 50.0 1-2 °C/°F
LAL (4) Minimum alarm. Temperature limit (whose
absolute or relative value status is regulated by
“Att”) below which the alarm is activated.
-50.0...HAL -50.0 1-2 °C/°F
PAO (5) Alarm exclusion time after start-up of instrument
following a power failure
0...10 0 1-2 hours
dAO Alarm exclusion time after defrosting
0...999 0 1-2 min
dOA Forced behaviour from digital input:
0=no enabling; 1=compressor enabled
2=fans enabled;
3=compressor and fans enabled
0/1/2/3 0 2 num
PEA Enables forced behaviour from door light and/or
from external alarm
0=function disabled; 1=associated with door light
2=associated with external alarm;
3=associated with door light and external alarm
0/1/2/3 0 2 num
dCO Delay in enabling compressor with consensus
0...250 0 2 min
dFO Delay in enabling fans with consensus
0...250 0 2 min
NOTE: At level 1 the folders will only display all the level 1 parameters. At level 2 the folders will only display all the
level 2 parameters. The level marked 1-2 allows the parameter to be displayed at both levels.
