Elkay EZH2O Series User Manual

PAGE 3
4420DBBFFR_FTN LK 4420DBBFFR_FTN
98880C (Rev. C - 12/15)
FINISHED FLOOR
4"
102mm
27"
686mm
19"
483mm
2 7/8"
73mm
WATER INLET
DRAIN LINE
22"
559mm
29"
737mm
64"
1626mm
8"
203mm
34 11/16"
881mm
ORIFICE
HEIGHT
44"
1118mm
14 9/16"
371mm
3"
76mm
O
10"
254mm
6 9/16"
167mm
30"
762mm
8 - O .500" HOLES
EQUALLY SPACED ON
TWO O 12.00" B.C.
PVC COLUMN CENTERED
BETWEEN MOUNTING
BOLT HOLES
O
14"
356mm
(2 PL)
G
F
H
A
J
F
G
E
D
C
H
A
SITE PREPARATION DETAIL
FIG. 2
LEGEND
A = ACCESS PANEL ( 8" X 10" )
B = REMOVABLE BOTTOM COVER
C = 1" PVC DRAIN
D = PRESSURE FITTING 1-1/4" x 3/4"
E = CONNECTOR 1-1/4" TO 1-1/4"
F = 1-1/2" DRAIN TUBE
G = AIR CONTROL LINE
H = WATER LINES
J = CONNECTOR FOR AIR CONTROL LINE
FIG. 1
SITE PREPARATION DETAIL FOR THE 4420BFDBFR FTN.
WHEN USING 98837C OR 98838C DUAL VALVE CONTROL ASSY.
4"
102mm
FROST
LINE
5 CUBIC FEET
POROUS FILL
( LARGE BROKEN FILL )
DRAIN LINE BY INSTALLER
( AS REQUIRED BY LOCAL CODES )
WATER INLET LINE
( BY INSTALLER )
CONCRETE SLAB
BACK FILL
( DIRT )
21"
533mm
MIN.
FROST LINE DEPTH
DEPENDANT ON
GEOGRAPHIC
LOCATION AND
LOCAL
REQUIREMENTS
36" MIN
67" MAX
12"
305mm
FILL LINE
MIN.

Elkay EZH2O Series Specifications

General

ADA Compliant	Yes
Activation Method	Push Button
Rated for Outdoor Use	Yes
Bubbler Material	Stainless Steel
Material	Stainless Steel
Mounting Type	Wall Mount
