PAGE 4
4420DBBFFR_FTN LK4420DBBFFR_FTN
98880C (Rev. C - 12/15)
26"
660mm
10"
254mm
O
57"
1448mm
B
22"
559mm
29"
737mm
O
10"
254mm
27"
686mm
37"
940mm
14 9/16"
371mm
3"
76mm
19"
483mm
8"
203mm
40 5/16"
1025mm
41 11/16"
1059mm
ORIFICE
HEIGHT
FINISHED FLOOR
A
6 9/16"
167mm
30"
762mm
O
14"
356mm
(2 PL)
*
8 - O.500" HOLES
EQUALLY SPACED ON
TWO
O12.00" B.C.
LEGEND
A = ACCESS PANEL ( 8" X 10" )
B = REMOVABLE BOTTOM COVER
ROUGH-IN FOR 4420BF1LDBFR
SEE PAGE 2 FOR FREEZE RESISTANT VALVE DETAILS (98837C)
FIG. 3
