Elkay EZH2O Series User Manual

PAGE 5
4420DBBFFR_FTN LK 4420DBBFFR_FTN
98880C (Rev. C - 12/15)
LEGEND A = ACCESS PANEL ( 8" X 10" ) B = REMOVABLE BOTTOM COVER
FIG. 4
ROUGH-IN FOR 4420BF1UDBFR
SEE PAGE 2 FOR FREEZE RESISTANT VALVE DETAILS (98837C)
8" 203mm
6 9/16"
167mm
30" 762mm
10" 254mm
O
64" 1626mm
19" 483mm
44"
1118mm
14 9/16"
371mm
29"
737mm
27"
686mm
33 5/16"
847mm
10" 254mm
O
26" 660mm
B
A
A
1-1/2" DRAIN
34 11/16"
881mm
ORIFICE
HEIGHT
O
10"
254mm
3" 76mm
*
O
14" 356mm
(2 PL)
22"
559mm
8 - O.500" HOLES
EQUALLY SPACED ON
TWO O12.00" B.C.

Elkay EZH2O Series Specifications

General

ADA Compliant	Yes
Activation Method	Push Button
Rated for Outdoor Use	Yes
Bubbler Material	Stainless Steel
Material	Stainless Steel
Mounting Type	Wall Mount
