Depress button for 3 seconds to activate main menu - release
Cycles through main menu items 2 seconds each for 3 cycles then exits menu unless selected. Cycles through sub menu items 2 seconds each for 3 cycles then returns to main menu unless selected. Selections are saved and exits menu when idle for 10 seconds Top Level Menu Action Sub Menu 1 Action Sub Menu/Action Action Sub Menu/Action Action Sub Menu/Action Notes End Action Set Day/Time Momentary 'URSVWRQH[WOHYHO
menu when selected
Day (Sunday - Saturday) Momentary Flash days of week on display waiting for signal of
selection, 3 cycles through days and display goes back to default.
'URSVWRQH[WOHYHO menu when selected
Hour (12 Hour) Momentary
Scroll hours from 1-12, 3 cycles through hours and display goes back to default.
'URSVWRQH[WOHYHO menu when selected
Minute (0-60 in 5min increments)
Momentary Scroll minutes from 0-60 in 5 minute increments, 3 cy-
cles through minutes and display goes back to default.
'URSVWRQH[WOHYHO menu when selected
AM/PM Momentary Scroll AM and PM, 3 cycles through AM/PM and display
goes back to default.
Returns to main menu
Filter Unit? Momentary
No Momentary 7XUQRII¿OWHUVWDWXVDQG
errors
1R¿OWHUXQLW/('ERDUGQRWXVHG*UDSKLFV'LVSOD\ GRHVQRWVKRZVWDWXV(UURUFRGHVUHODWHGWR¿OWHU turned off.
Returns to main menu
Yes Momentary 7XUQRQ¿OWHUVWDWXVDQG
errors
)LOWHUXQLWKDVGHIDXOWFRQ¿JRQGHIDXOWFRQ¿JKDVUHDG ZULWHWR¿OWHU/('RU*UDSKLFVVWDWGLVSOD\¿OWHUHUURU capability.
Returns to main menu
Refrigeration Unit?
No Momentary Turn off all regrigeration
controls
Refrigeration off Returns to main menu
Yes Momentary Set unit to operate as
refrigerated unit
Refrigeration on Returns to main menu
Flow Rate?
High Momentary Set Water Rate 1.5 Gal/Min Set water rate setting to 1.5gal/min. Returns to main menu
Low Momentary Set Water Rate 1.1 Gal/min
Set water rate setting to 1.1gal/min. Returns to main menu
Water Temperature Momentary
Cold Momentary Set to “Cold” Temperature $SSUR[) Returns to main menu Colder Momentary Set to Default Temperature
$SSUR[) Returns to main menu
Coldest Momentary 6HWWRGH¿QHG³&ROGHVW´
Temperature
$SSUR[) Returns to main menu
Backlight Setting Momentary Set Backlight/Alcove
light in idle mode
Momentary
Backlight settings are: 1=25%, 2=50%, 3=75% and 4=100%
1 (= 25%) Momentary Returns to main menu 2 (=50%) Momentary Returns to main menu
3 (=75%) Momentary Returns to main menu
4 (=100%) Momentary Returns to main menu
Energy Save Mode Momentary
Off Momentary Default operation
Unit runs with control board controlled refrigeration on
always.
Returns to main menu
On Momentary
Set Energy Save Schedule Unit refrigeration is shut off based on schedule. 'URSVWRQH[WOHYHO
menu when selected
Select Weekdays (default when no time is selected = Always off)
Weekdays (Monday - Friday) schedule settings 'URSVWRQH[WOHYHO
menu when selected
Momentary Select Time on 24 Hours - 1-12AM and 1-12 PM 'URSVWRQH[WOHYHO
menu when selected
Momentary Select Time off 24 Hours - 1-12AM and 1-12 PM 'URSVWRQH[WOHYHO
menu when selected
Select Weekend Weekend (Saturday and Sunday) scheduled settings. 'URSVWRQH[WOHYHO
menu when selected
Momentary Select Time on
24 Hours - 1-12AM and 1-12 PM 'URSVWRQH[WOHYHO
menu when selected
Momentary Select Time off 24 Hours - 1-12AM and 1-12 PM Returns to main menu
View Error Codes Momentary Flashes Error Codes 2 seconds each / 3 cycles through codes Returns to main menu
Clear Error Codes Momentary Are you sure? Momentary Yes - Clear error modes
Clears all error codes in control board memory. ([LW0HQX
Programming Instruction
