Page 10
EZSDWS*1F EZS8WS*1F, 2F 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F
1000001731 (Rev. A - 3/14)
B CA
SIMPLY PUSH IN
TUBE TO ATTACH
TUBE IS SECURED
IN POSITION
PUSH IN COLLET
TO RELEASE TUBE
OPERATION OF QUICK CONNECT FITTINGS
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
Fig. 17
DESCRIPTION
1
2
3
ITEM NO. PART NO.
51300C
98926C
51469C
Filter Assy-3000 Gal.
Kit-Filter Head Fitting includes
John Guest Fitting & 3/8”
Elbow Fitting
Assy -Filter & Bracket
includes Fltr Head/Mtg Bkt/
John Guest Ftgs/Screws
DESCRIPCIÓN DESCRIPTION
Ensamblado del Filtro-3000 Galón
Montaje Cabeza Kit Filtro-Incluye John
Guest Montaje y 3/8” Codo
Conjunto del Filtro y Soporte, Incluye
Filtro Soporte/John Guest Guarniciones/
Tornillos de Montaje de Cabeza
Ens. ltre-3000 Gallon
Raccord Tête de Filtre Kit-InclutJohn
Guest Montage et 3/8” Raccord en
Coude
Assemblêe-Filtre et Support Inclut
Filtre/Montage Support/John Guest/
Vis à Têtê
WATERSENTRY
®
FILTER PARTS LIST
(See Fig. 17)
LISTA DE PIEZAS DEL FILTRO
(Vea la Fig. 17)
LISTE DES PIÈCES DU
FILTRE (Voir Fig. 17)
WATERSENTRY
®
Filter Detail
Detalle WATERSENTRY
®
Filtro
Description WATERSENTRY
®
Filtrage
3
2
2
1
2
Fig. 15
Note: Screw the locknut hand tight to seal
Fig. 16
