Page 6 of 8
Service Counter
The Mini Std V7 has a settable service interval counter that can be set via the S1
Dipswitches, each dipswitch equates to a set number.
S1 Dipswitch
D/Sw Count D/Sw Count
1 1,000 5 30,000
2 5,000 6 40,000
3 10,000 7 50,000
4 20,000 8 Not used
Setting the Service Interval Counter:
1) Note and record all S1 Dipswitch settings
2) Set ALL S1 Dipswitches to OFF
3) Set S1 Dipswitch 8 to ON
4) Set only one other S1 Dipswitch to ON
5) Press simultaneously the OWR, CLOSE and OPEN pushbuttons for 3-seconds
6) The Service LED will illuminate for 3-seconds to confirm
7) Return ALL S1 Dipswitches to their original settings and test the door for correct operation
Resetting the Service Interval Counter
1) Press simultaneously the OWR, CLOSE and OPEN pushbuttons for 3-seconds
2) The Service LED will illuminate for 3-seconds to confirm
Disabling the Service Interval Counter
1) Note and record all S1 Dipswitch settings
2) Set ALL S1 Dipswitches to ON
3) Press simultaneously the OWR, CLOSE and OPEN pushbuttons for 3-seconds
4) The Service LED will illuminate for 10-seconds to confirm
5) Return ALL S1 Dipswitches to their original settings and test the door for correct operation
LED Status Indicators
LED Description Colour Status Description of status
D5 POWER Green ON 24VDC supply is ON
D8 SAFETY FAIL Amber Flashing
S1 D/SW 6 is ON (but no signal from the
safety edge)
Amber ON
Open circuit safety device(s) / incorrectly
set S1 D/SW 5
D10 STOP RED ON
Open circuit Stop circuit / incorrectly set
limit switches
RED Flashing Auto-Close Timer learning mode
D12 SPEED/RUNT. Red ON Run Time of door has expired
Red Flashing Service Indicator - Door requires servicing
D14 CLOSE limit switch Amber ON Open circuit limit switch - Close
D15 OPEN limit switch Amber ON Open circuit limit switch - Open
D16 OPEN pushbutton Amber ON OPEN pushbutton is ON
D17 CLOSE pushbutton Amber ON CLOSE pushbutton is ON
