Owner’s Manual
6. Close the brake quick release. See the Brakes section
above for detailed instructions on closing your brake
quick release system.
WARNING! Always check to ensure that the brake
quick release system is properly closed before riding
your bike. If the brake quick release is not in the closed
position, the brake will be inoperable. Inoperable brakes
are extremely dangerous and drastically increase the
likelihood that the rider will collide with another object
and suer serious injury or death.
7. Tighten both wheel nuts to 30 N-m using a 15mm
wrench.
WARNING! During riding, the rear wheel is subject to
a significant amount of force that is transferred through
the chain to the rear cog. Failure to properly secure the
wheel nuts could result in them becoming loose over
time. If the nuts become loose, they could cause the
wheel to move unexpectedly and contact the brakes
or frame. This could cause the rider to lose control and
suer a fall. Make sure you check these nuts before every
ride and ensure they are tightened to 30 N-m.
8. Install shifter cable back into the hub.
a. If you have a 3C, shift into 3rd gear. If you have
an 8S, use the finger lever to shift into 1st gear.
If you have an 11R, use the finger lever to
shift into 11th gear. If you have an 8C where
actuating the finger lever INCREASES gears, use it
to shift into 8th gear. If you have an 8C where
actuating the finger lever DECREASES gears, use it
to shift into 1st gear.
6
7
8
b. With one hand rotate the spring loaded shifter
pulley clockwise, while hooking the shifter cable
into the groove on the pulley with the other hand.
Spin the wheel to ensure the wheel spins freely, if it
rubs, follow steps 5-8 to re-align the rear wheel.
WARNING! If your rims are damaged, cracked
or worn out, or brake rubbing persists, DO NOT
RIDE. Instead, consult a bicycle mechanic or contact
ElliptiGO® Customer Service.
