ELMAC Galileo Pro Ticket Eater - Mian PCB Connectors

21
MIAN PCB CONNECTORS
CN13 Power supply
1 230 Vac
2 Ground
3 230 Vac
4 GND
5 GND
6 GND
7 +5Vcc
8 +12Vcc
9 +24Vcc
CN3 Display
1 Clock
2 Data
3 +5 Vcc
4 N.C.
5 Strobe
6 N.C.
7 +5 Vcc
8 +5 Vcc
9 GND
10 GND
11 GND
12 GND
13 GND
14 +12 Vcc
15 +12 Vcc
16 +12 Vcc
CN9 Feeding - Buttons
1 Lamp
2 GND
3 N.C.
4 N.C.
5 N.O. Button – IN
Card Swipe Mode
6 GND
7 OUT Card Swipe
Mode
8 N.C.
9 N.C.
10 +5 Vcc
11 + Card reader
12 Lamp
13 +12 Vcc
14 Common Button
15 GND Card reader
CN1 Sensors
1 GND
2 GND
3 +5Vcc
4 +5Vcc
5 Full Sack sensor
6 Width tck sensor
7 Sensor 1
8 Sensor 2
9 Sensor Input
10 “Mouth” lights
CN10 Printer feeding
1 GND
2 +24 Vcc
CN2 230 Vac - Motor
1 230 Vac in
2 Ground
3 230 Vac in
4 230 Vac to the
motor
5 Ground to the
motor
6 230 Vac to the
motor
CN14 Header
1 +12Vcc
2 GND
3 Speaker
4 Speaker
CN4 – CN5 – CN7
1 N.C.
2 Rx
3 GND
4 GND
5 Tx
6 N.C.
