3
HOW
TO
PROGRAM
A
PERSONALIZED
LOGO .................................................................................15
REPLACING
THE
SACK .....................................................................................................................15
REPLACING
THE
PAPER
FOR
THE
PRINTER......................................................................................15
ELIMINATION
PAPER
BLOCKAGES ..................................................................................................16
CLEANING
THE
DRAGGING
AND
CUTTING
UNIT.............................................................................16
PROBLEMS
AND
SOLUTIONS ..........................................................................................................18
WIRING
DIAGRAM……………………………………………………………………………………………………………………20
MIAN
PCB
CONNECTORS................................................................................................................21
DECLARATION OF CONFORMITY ..................................... 22
WEEE
MARK....................................................................................................................................23
Description
The Mangia Tickets mod. GALILEO is an automatic machine for counting and
destroying tickets. It is user friendly, and has a Dot Matrix display which shows
the number of tickets counted by the machine.
If connected to a computer, through “WinMT software” it offers a solution for
complete automated management of PRIZE DESK OPERATIONS.
The internal printer prints personalized receipts, with logos and operator
configurable notices/information e.g. expiry dates for receipts
TECHNICAL CHARACTERISTICS
Feeding tension: 230 Vca~50Hz
Absorption: 250W
Counting speed: ~ 640 tickets/min.
Sack capacity: ~ 50.000 tickets
Printer: Custom TPTCM60
Thermal with auto-cutter and automatic expulsion
~ 2.400 receipts with 130mm roll
Badge reader: Uniform Ind. 3 tracks ISO
Display: Dot-graphic matrix display 48*8
Alphanumeric display with 16*2 characters
Pc Interface: Serial Rs232, 9600 bps
Mechanic group: Special patented mechanics mod. “GALILEO”
Mono-phase motor 220 Vac/0.6A
Adapter in oil bath
Helical self-sharpening blades
DIMENSIONS AND WEIGHT
Height: 150 (176 cm with heading)
Width : 50 cm
Depth: 40 cm
Weight (with empty sack): 70 Kg
