ELMECO BB1 User Manual

- 53 -
Impianto Elettrico / Electric System / Installation Electrique / Instalación Eléctrica
I
1: Interruttore generale
A: Filtro antidisturbo (opzionale _ solo 230V/50Hz)
C: Compressore
R: Relè compressore (solo BB1 115V/60Hz e 100V/50-60Hz)
Rc: Resistore ceramico 15K7W (solo BB1 115V/60Hz e
100V/50-60Hz)
Pr: Pressostato (su BB1 solo alcuni modelli)
FM: Motoventilatore
M1/M2: Motoriduttore brushless
EB1/EB2: Modulo elettronico
EV1/EV2: Elettrovalvola
9: Fusibile 5X20 F315mA
Q1/Q2: Termostato
TM: Timer (opzionale X BB2)
8: Interruttore timer
AS: Alimentatore switching 100-240Vac/24Vdc
Colori
BRN Marrone
BLU Blu
GRN Giallo/Verde
RED Rosso
BLK Nero
WHI Bianco
GRY Grigio
VIO Viola
ORA Arancione
GB
1: Main switch
A: Suppressor filter (optional _ only 230V/50Hz)
C: Compressor
R: Compressor relays (only BB1 115V/60Hz and 100V/50-60Hz)
Rc: Ceramic resistor 15K7W (only BB1 115V/60Hz and 100V/50-
60Hz)
Pr: Pressure switch (on BB1 only some models)
FM: Fan motor
M1/M2: Brushless gear motor
EB1/EB2: Electronic board
EV1/EV2: Solenoid valve
9: Fuse 5X20 F315mA
Q1/Q2: Thermostat
TM: Timer (optional only BB2)
8: Timer switch
AS: Switching power supply 100-240Vac/24Vdc
Colors
BRN Brown
BLU Blue
GRN Yellow/Green
RED Red
BLK Black
WHI White
GRY Grey
VIO Purple
ORA Orange
