A: Filtro antiparásito (230V/50HZ)
1: Interruptor general
Pr: Presostato
LPr: Luz de interruptor de presión
C: Compresor
FM: Motoventilador
AS: Interruptor de alimentación elect.
EV1: Electroválvula
9: Fusibile 5X20mm F315mA
M1: Motoreductora
EB1: Modulo electronic B0005130-001
D1: Driver brushless
q1: Termostato PT1000
r1: Sensor lector
A1: Control Electrónico de potencia
Color
BRN Marron
BLU Azul
GRN Verde
RED Rojo
BLK Negro
WHI Blanco
GRY Gris
VIO Violeta
ORA Naranga
YEL Amarillo
A: Suppressor filter (230V/50HZ)
1: Main switch
Pr: Pressure switch
LPr: Pressure switch light
C: Compressor
FM: Fan motor
AS: Single Output Switching Power Supply
EV1: Solenoid valve
9: Fuse 5X20mm F315mA
M1: Brushless gear motor
EB1: Electronic board B0005130-001
D1: Brushless driver
q1: PT1000 thermostat
r1: Reed sensor
A1: Amperage control board
Colors
BRN Brown
BLU Blue
GRN Yellow/Green
RED Red
BLK Black
WHI White
GRY Grey
VIO Purple
ORA Orange
YEL Yellow
