ELMECO Quickream User Manual

- 39 -
ES
GB
#
REFERENCIA
CODES
DESCRIPCIÓN
DESCRIPTION
1
B0004107-002
JUNTA TÓRICA OR2106
FOOD SYLICON SLEEVE HOLDING GASKET OR2106
2
B0004101-002
MANGUITO QUICKREAM
QUICKREAM SLEEVE
3
B0000110-001
PASADOR CILINDRICO 4X35MM INOX A2
STEEL CYLINDRICAL PLUG 4X35MM
4
B0003108-002
CONEXIÓN LEVA DERECHA NYLON NEGRO
BLACK NYLON RIGHT LEVER CONNECTION
5
B0003106-001
CONEXIÓN LEVA
CONNECTIONS JUNCTION AXSIS
6
B0003111-001
JUNTA SILICONA DE156
SILICON TAP RELIEF GASKET DE156
7
B0003109-003
PISTON GRIFO COMPLETO QUICKREAM
QUICKREAM COMPLETE DRAIN PISTON
8
P0006105-001
TORNILLO M4X10MM INOX
STEEL SCREW
9
B0003107-002
CONEXIÓN LEVA IZQUIERDA NYLON NEGRO
BLACK NYLON LEFT HANDLE BRIDGE
10
B0003120-001
PALANCA NEGRO QUICKREAM
QUICKREAM BLACK HANDLE
11
B0003112-002
JUNTA TORICA OR3118
PISTON SILICON GASKET OR 3118
12
B0003101-001
VÁLVULA ESTRELLA QUICKREAM
STAR SUPPLY VALVE
13
B0006109-002
TAPA DEPÓSITO QK CON BLOQUEO
TRANSPARENT COVER WITH KEY LOCK
14
B0000102-003
DEPÓSITO TRANSPARENTE QUICKREAM
QUICKREAM TRANSPARENT TANK
15
M0000107-001
ABRAZADERA PALA HORIZONTAL
VERTICAL BLADE FIXING RING
16
B0000106-001
EJE DE TRANSMISIO CON TUERCA INOX
STEEL SHAFT WITH STEEL NUT
17
L0000106-001
JUNTA DE DEPÓSITO BB/QK
TANK GASKET BB/QK
19
M0000104-001
CASQUILLO ARBOL DE TRANSMISION
TRANSMISSION SHAFT BUSHING
20
B0000103-003
ARBOL DE TRANSMISION QK CON CASQUILLO
QUICKREAM TRANSMISSION SHAFT WITH BUSHING
21
B0004108-001
QUICKREAM PALA HORIZONTAL COMPLETA CASQUILLO
2014 VERS.
QUICKREAM HORIZONTAL AUGER COMPLETE OF BUSHING 2014
VERS.
22
A0000114-001
JUNTA ARBOL DE TRANSMISION
TRANSMISSION SHAFT GASKET
23
M0000120-001
TUERCA CUADRADA D5 HIERRO ZN UNI 5597
D5 SQUARE NUT
24
M0006103-003
BISAGRA POSTERIOR NEGRO
BLACK REAR HINGE
25
M0001101-001
TORNILLO GALVANIZADO 5X12
TE GALVANIZED SCREW 5X12
26
B0002101-002
EVAPORADOR QUICKREAM NEGRO
QUICKREAM COMPLETE BLACK TANK
27
M0000105-001
ABRAZADERA ARBOL
SHAFT FIXING RING
28
DADOD.6ZFL
TUERCA M6
M6 NUT
29
A0000115-001
TORNILLO M5X20MM
SCREW TE M5X20MM
30
B0000117-001
PASADOR CON ROSCA + TUERCA M3 QK
KIT SCREW+NUT M3 BRUSHLESS/TRANSMISSION QK
31
B0005102-001
MOTORREDUCTOR
BRUSHLESS GEARMOTOR 24VDC
32
M0006115-003
BISAGRA ANTERIOR NEGRO
BLACK FRONT HINGE
33
M0006102-003
GANCHO BISAGRA NEGRO
BLACK HINGE HOOK
34
M0006119-001
TORNILLO FIJACIÓN M5X25mm
SPLINED KNOB
39
M0006116-003
BASE NEGRO
BLACK BASE
55
B0005101-001
TERMOSTATO ELECTRONICO PT1000 QUICKREAM
ELECTRONIC THERMOSTAT PROBE COMPLETE
94
B0006113-001
CLAVE PARA DESBLOQUEAR TAPA DEPÓSITO QK
COVER UNLOCK KEY
98
A0000117-001
CASQUILLO MOTORREDUCTOR / ALBERO
GEAR MOTOR BUSHING
101
M0004102-002
PALA HORIZONTAL CASQUILLO 2012 VERS.
HORIZONTAL AUGER BUSHING 2012 VERS.
104
B0004113-001
QUICKREAM PALA VERTICAL + CASQUILLO
QUICKREAM VERTICAL AUGER + BUSHING
105
B0004110-004
PALA VERTICAL PIÑÓN
VERTICAL AUGER GEAR
106
B0004112-004
PALA HORIZONTAL PIÑÓN
HORIZONTAL AUGER GEAR
107
B0003118-001
MUELLE DE CIERRE DEL GRIFO
TAP CLOSING SPRING
108
B0003115-001
CHAVETA DE BLOQUEO DEL MUELLE
SPRING LOCKING PIN
109
B0003119-001
SOPORTE DE REDUCCIÓN DE APERTURA DEL GRIFO
OPENING TAP REDUCTION BRACKET
