User Manual: Interactive Digital Signage
SW602296 Rev A, Page 23 of 39
Magnetic Stripe Reader (MSR) Functionality (Optional
Peripheral)
The MSR shall operate in keyboard mode.
Capable of reading 3 tracks simultaneously.
Security level and Encryption function: OFF
CEC Functionality (Consumer Electronic Control)
The touchmonitor is equipped with CEC capability. If a host device (with CEC built in) is
connected to the monitor through HDMI, the monitor can be turned on by only turning the host
device on.
Real Time Clock (RTC) Functionality
This touchmonitor has real time clock functionality which will help to prolong the lifetime of the
touchmonitor. In the OSD menu, there is a sub-menu called RTC Settings.
To utilize the RTC functionality:
The user must set up the Time setting for their specific time zone.
When the On/Off Schedule is Enabled, the user can choose when to leave the monitor on and
when it should be off. Individual or multiple days can be chosen.
Example:
Have the monitor ON for Monday, Wednesday and Friday between 9:00AM and 5:00PM. All
other days and time, the monitor shall be OFF.
o Enable the On/Off Schedule
o Select M W F
o Set the ON time for 09:00:00 and the OFF time for 17:00:00
Note that all of time settings operate on the 24-hour clock.
