Touchmonitor Specifications
Model ET1247L
LCD Display
12.1” TFT Active Matrix Panel
Display Size
246(H) x 184.5(V) mm
Pixel Pitch
0.3075(H) x 0.3075(V) mm
Display Mode
VGA 640 x 350 (70 / 85Hz)
VGA 720 x 400 (70 / 85Hz)
VGA 640 x 480 (60 / 72 / 75 / 85Hz)
SVGA 800 x 600 (56 / 60 / 72 / 75Hz)
Max. Resolution
SVGA 800 x 600
Contrast Ratio
300 : 1 (typical)
Brightness
300 Cd/m
2
wo/touch; 275 Cd/m
2
w/IT touch
Response Time
50 ms (typ.) / 100 ms (max.)
Display Color
262K
Viewing Angle
+60
o
~ -60
o
(L/R), +40
o
~-50
o
(U/D) (typical)
Input Signal
Video R.G.B. Analog 0.7V
peak to peak
Sync TTL Positive or Negative
Signal Connector
15 Pin Mini D-Sub
Rear Control
Power on / off , Menu / Select (up, down),
Adjustment (+, -)
Brightness, Contrast, Contrast, Color, Auto Tune
OSD
H/V-Position, Frequency, Phase, Track, Text/GRP,
Mode Inf., Recall
Plug & Play
DDC1 / 2B
Touch Panel (optional)
IntelliTouch
Power Adapter
Input AC 100-240V, 50-60Hz, Output DC 12V/2.5A
(max.)
Operating Conditions
Temperature 0
o
C ~ 50
o
C (41
o
F ~ 95
o
F)
Humidity 20% ~ 85% (No Condensation)
Altitude To 10,000 Feet
Storage Conditions
Temperature -20
o
C ~ 60
o
C (-4
o
F ~ 140
o
F)
Humidity 5% ~ 95% (No Condensation)
Dimensions (HxWxD)
242 x 302.5 x 60mm
Weight (Net)
Certifications
4Kg
, TUV-BAUART, FCC, CE, C-Tick, MPR II and VCCI

Elo TouchSystems Entuitive 1247L Series Specifications

General

Brand	Elo TouchSystems
Model	Entuitive 1247L Series
Category	Monitor
Language	English
