Elson 170zd - Spare Parts Identification

18
SPARES
Table5:Spares
Fig.11:IndirectCylinderSparesDiagram
14 9 12
625 13
5 1 6 13
9 12
14
4 6 13
5 1 6
13
9 8 11
Item
Number
Description PartNumber
1 Immersion heater (Bent) 95606984
2 Immersionheater(Straight) 95606986
3 Solarpocketplateassembly 95607064
4 Blankingplateassembly 95605881
5 Immersionheatergasket 95611822
6 Immersionheaterbacknut 95607869
7 Immersionheaterkey
spanner
95607861
8 Indirect thermostat &
thermalcut-out
95612716
9 Direct thermostat & thermal
cut-out
95612717
10 Solarthermalcut-out 95612698
11 6Wayterminalblock 95607933
12 3Wayterminalblock 95607932
13 Terminal cover 95614095
14 Temperature/Pressure
reliefvalve
95605810
15 Tundish 95605838
16 Expansionvalve-complete
-0.6MPa(6Bar)
95607030
17 Coldwatercombination
valve-complete
95605047
18 Motorised2portvalve 95605049
19 AccessoryKit-Indirect
(without expansion vessel)
95607968
20 AccessoryKit-Direct
(without expansion vessel)
95607969
21 Expansionvessel-12litre
(120&150litremodels)
95607863
22 Expansionvessel-18litre
(170&210litremodels)
95607864
23 Expansionvessel-24litre
(250&300litremodels)
95607612
Fig.12:DirectCylinderSparesDiagram
