Elstat EMS-55-R User Manual

24
TECHNICAL DATA
Input voltage
12 Volt AC (from Elstat transformer)
Maximum switch capacity per UL rating
(120VAC/230VAC)
Compressor 16 A FLA, 96 A LRA
0.4 – 0.5 p.f.
Fan relay 4.4 A FLA
Light relay 2.2 A FLA
Maximum switch capacity per VDE rating
(120VAC/230VAC)
Compressor 12 A , p.f. 0.6
Fan relay 6 A , p.f. 0.6
Light relay 2.08 A , p.f. 0.3
(fluorescent lamps 500 W)
Accuracy
Appliance sensor 0.5
O
C
Condenser sensor +/- 5
O
C
Resolution
0.1
O
C
Display
15 mm – 7 segment – LED
LED/display colour
Green
Sensor(s)
Thermistor (NTC)
Sensor wire length
1 @ 1.5 mtr +/- 2.5 %
1 @ 2.5 mtr +/- 2.5 %
*Different lengths available upon request.
Step down transformer
230Vac/ 12 Vac
120Vac/12Vac
100Vac/12Vac (Japan only)
Housing material
Black Polycarbonate (Lexan-940)
Maximum ambient operating temperature
65
O
C. (55
O
C in USA)
IP rating
Front 65 / Rear 10
Motion detection range
5 metres in front of detector
Connections: Line voltage
Low voltage
Spade terminal 6.35 x 0.8 mm.
Screw terminal connections
APPROVALS
CE
European Low Voltage Directive
VDE
Verband der Elektrotechnik
UL
Underwriters Laboratories Inc.
Please note that this manual is based upon EMS firmware version E46. Please see
supplement sheet which states the differences between E46 and the older firmware
version E43.
