54 User Manual THEIA HE-t String Inverters 357115.013, Issue 1.0, 2011 March
Inverter Setup
Displays the various data for the specific inverter. This information is set during the
manufacturer process. The information is used by service and maintenance personnel.
Model
Inverter model
Serial Number
Unique identifier for each inverter. Also to be found on the product
label
THEIA Part Number
Identifier for each inverter hardware configuration within Eltek Valere
THEIA Version
Unique version name for keeping track of the development of different
inverter versions within Eltek Valere
GUI Software Part No
The GUI (Graphical User Interface) software part number. GUI allows
interaction with the inverter through the display
GUI Software Version
Version number for the GUI software
GUI Hardware Part No
Identifier for the GUI-card hardware
GUI Hardware Version
Version number for the GUI hardware
SW1 Part No
The DSP1 (Digital Signal Processing) software part number. DSP is a
microprocessor controlling the power conversion in the inverter
SW1 Version
Version number for the DSP1 software
Control Board Part No
DSP-card hardware part number
Control Board Version
Version name for the DSP control card hardware
Main Board Part Number
Identifier for the PCB (Printed Circuit Board) hardware. PCB hosts all
the components and subsystems of the inverter
Main Board Hardware
Version
Unique version number for keeping track of the development of
different main board versions
SW2 Part No
The DSP2 software part number
SW2 Version
Version number for the DSP2 software
Grid Setup
Displays grid settings based on the selected country. The settings can be changed using the
password within 5 hours of feeding in power to the grid after installation. Thereafter it is only
accessible by using the Installer password, which may only be obtained by contacting Eltek
Valere.
Country
Country of the installation
Country code
Name of the grid protection standards
Grid nom voltage
Nominal voltage of the grid on site
Grid nom frequency
Nominal frequency of the grid on site
Voltage limit min
Lower disconnection limit of the grid voltage on site
Voltage limit max
Upper disconnection limit of the grid voltage on site
Voltage time limits min
Minimum disconnection time limit
Voltage time limits max
Maximum disconnection time limit
Frequency limits min
Lower disconnection limit of the grid frequency on site
Frequency limits max
Upper disconnection limit of the grid frequency on site
Frequency time limits min
Minimum disconnection time limit
Frequency time limits max
Maximum disconnection time limit
