ELTEX ESR-100 Quick Start And Installation Guide

14 ESR series routers
5. ROUTER COMMAND LINE INTERFACE CONNECTION (CLI)
5.1. Ethernet local network connection
The router loads with the factory configuration during the first start. Factory configuration
is described in chapter 4 of the document.
Step 1. Connect data transmission network cable (patch-cord) to any port of «trusted» area and to
the computer assigned for management.
Step 2. DHCP-server with IP-address pool in 192.168.1.0/24 subnet is activated in the factory router
configuration.
Network interface of control computer should get network address from server during the
connection.
If IP-address is not received for any reason than you should manually set interface address by using
any address in 192.168.1.0/24 subnet except 192.168.1.1.
5.2. Connection through RS-232 console port
Step 1. Connect «Console» port of the router to computer port by RJ-45/DB-9 cable that is included
in the device delivery package.
Step 2. Run terminal program (for example, HyperTerminal or Minicom) and create new
connection. You must use emulation mode of VT100 terminal.
Run the next RS-232 interface settings:
 Bit rate: 115200 bps;
 Data bit: 8 bit;
 Parity: No;
 Stop bits: 1;
 Flow control: No.
