16 ESR series routers
6.3. Device name destination
The next commands are used to assign device name:
esr-1000# configure
esr-1000(config)# hostname <new-name>
After applying of the configuration, command prompt will be changed to value that is assigned by
<new-name> parameter.
6.4. WAN parameters settings
You need to assign device parameters determined by a provider (IP-address, subnet mask and
gateway address by default) to adjust router network interface in public network (WAN).
Command examples of the Static IP-address configuring for subinterface GigabitEthernet 1/0/2.150
to access the router through VLAN 150.
Interface parameters:
Buffer zone – untrusted
IP address – 192.168.16.144;
Subnet mask – 255.255.255.0;
Gateway IP-address by default – 192.168.16.1.
esr-1000# configure
esr-1000(config)# interface gigabitethernet 1/0/2.150
esr-1000(config-subif)# security-zone untrusted
esr-1000(config-subif)# ip address 192.168.16.144/24
esr-1000(config-subif)# exit
esr-1000(config)# ip route 0.0.0.0/0 192.168.16.1
Enter the next command after applying of the configuration to check that the address was assigned
to interface:
esr-1000# show ip interfaces
IP address Interface Type
------------------- ----------- -------
192.168.16.144/24 gi1/0/2.50 static
Provider can use dynamically assigned addresses in network. DHCP-protocol can be used to get IP-
address if DHCP-server is in network.
Adjustment example assigned for getting of the dynamic IP-address from DHCP-server on the
GigabitEthernet 1/0/4 interface:
esr-1000# configure
esr-1000(config)# interface gigabitethernet 1/0/4
esr-1000(config-if)# ip address dhcp
esr-1000(config-if)# end
esr-1000 #commit
esr-1000 #confirm
Enter the next command after configuration applying to check that the address was assigned to
interface:
esr-1000# show ip interfaces
