266 Universal Network Terminal TAU-72.IP/TAU-36.IP
Wire colour and terminal contact correspondence table (HANDIAN UTP 18PR cable)
Wire color
Connector contact
Wire color
Connector contact
White-blue
1
Red-grey
10
Blue
19
Grey
28
White-orange
2
Black-blue
11
Orange
20
Blue
29
White-green
3
Black-orange
12
Green
21
Orange
30
White-brown
4
Black-green
13
Brown
22
Green
31
Purple-grey
5
Black-brown
14
Grey
23
Brown
32
Red-blue
6
Black-grey
15
Blue
24
Grey
33
Red-orange
7
Yellow-blue
16
Orange
25
Blue
34
Red-green
8
Yellow-orange
17
Green
26
Orange
35
Red-brown
9
Yellow-green
18
Brown
27
Green
36
