Safety Check
CAUTION!
DISCONNECT ELECTRICAL POWER PRIOR TO INSTALLING THE ELUMINOCITY
GRIDCHARGE. FAILURE TO DO SO MAY CAUSE PHYSICAL INJURY OR DAMAGE
TO THE ELECTRICAL SYSTEM AND CHARGING UNIT.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS.
The eluminocity GridCharge shall be installed only by a licensed contractor, and/or a licensed
electrician in accordance with all applicable state, local and national electrical codes and
standards. Before installing this product, ensure compliance with local building practices,
climate conditions, safety standards, and state and local codes. Use appropriate protection
when connecting to the main power distribution cable.
WARNING: Danger of electrical shock or injury. Turn OFF power at the panelboard or load
center before working inside the equipment or removing any component. Do not remove
Grounding Instructions
The eluminocity GridCharge must be connected to a grounded, metal, permanent wiring
system; or an equipment grounding conductor must be run with the circuit conductors and
connected to the equipment grounding terminal or lead on the product.
Recommended Tools
The following tools are recommended for eluminocity GridCharge installation:
– Vendor-supplied accessories and components:
■ Mounting bracket
■ Cable hanger bracket (optional)
■ Torx T30 bolts (x2) for securing the AC Charger to the mounting bracket
■ 1/4 inch expansion bolts (x3)
■ No. 8 wood screws (x3)
– Installer-supplied components:
■ Conduit of appropriate trade size for power wire
■ NEMA 6-50P receptacle
■ Electrical box and wallplate
– Recommended tools:
■ Torx T30 screw driver
■ Torx T20 screw driver
■ Phillips #2 screw driver
■ Flathead slotted #5 screw driver
■ Terminal crimper
■ Stud finder
■ Level
