1- Characteristics
Control panel for governing sliding gear motors, 230/120 Vac with 600 W rated power, equipped with inputs for limit switch, encoder (used for
obstacle detection and speed control) and integrated receiver. The control panel enables:
- customizing the space and speed of deceleration in both opening and closing phases
- equipped with an obstacle detection system (if there is an encoder circuit)
- LED for input diagnostics
- removable data memory
- integrated receiver with capacity for 128 remote control codes (hard coded or rolling code)
2- Description
Fig. 1
F2 (5x20)
F 5A
F1 (5x20)
F 630mA
12345678
9101112
13 14 15 16 17 18 19 20 21 22 23
2524
ON
ON
1 2
1234 5 678
IBRIDO RX
