9
Dual Band Mode
Dual Band mode functions basically the same as Full Range, but
it gives you more tweakability by assigning the attack and sus-
tain controls to individual frequency selectors.
The Freq A controller now sets the start frequency for attack processing,
while the Freq S controller determines the end frequency for sustain pro-
cessing. The function of the Attack and Sustain controllers remain the
same as in Full Range mode.
Note: Auto Gain is not oered in this mode as it is typically not needed in
dual band operation.
Linked Dual Band
Unlinked Dual Band
