Tinyhawk III Plus Freestyle
1. Distance Adjustment Slot
2. Frequency Band Switch Button
3. Channel Switch Button
4. Recording Button
5. Audio Interface
6. Micro USB Port
7. Recording Indicator Light
8. Charging Indicator Light
9. Antennas
10. Auto Search Button
11. Power On/Off (Long Press) & Menu Button (Short Press)
12. Reset Button
13. SD Card Slot
14. Head Strap Attachment Hole
15. Sponge Pad
16. External Bracket Connection Port
Feel free to reach out if you have any more questions or need further assistance!
Regenerate
Note: To operate the Transporter II correctly, please perform the following
steps: Install the provided antennas onto the SMA connectors. When wearing
the goggles, make sure to separate the antennas from the USB power cable
used for charging.
3.2 Transporter II Specifications
Maximum Dimension (excluding antennas, folded state): LxWxH =
155x100x90mm
Weight (excluding battery): Approximately 398g (including head strap and
antennas)
Screen Resolution: 480x800
Display Screen Size: 4.3 inches
Battery: Built-in 1300mAh lithium-ion battery
Operating Voltage: 4.2V-3.7V
Operating Frequency: 5.8GHz frequency band (5658MHz-5945MHz)
Charging System: Built-in USB 1A linear lithium-ion battery charging
system
DVR: Supports up to 32GB TF card, compression format MJPEG, file format
AV
Recording Size: VGA/D1/HD (Three modes available)
Record Time: Off/3 minutes/5 minutes/10 minutes (Selectable)
