Emerson 1F83-0422 - Troubleshooting; Comfort Alert Codes

8
PROGRAMMING
TROUBLESHOOTING
Comfort Alert Codes
The Comfort Alert diagnostics product monitors the air
conditioning outdoor systems with single phase Copeland
Scroll compressors. Abnormal system and electrical
conditions are indicated by flashing ALERT codes on the
yellow LED on the Comfort Alert module. The flash codes are
transmitted to the thermostat by the Comfort Alert Thermostat
interface module. The Comfort Alert compatible thermostat
displays “Call For Service” that flashes at the same rate as
the yellow LED on the Comfort Alert module.
Comfort Alert Yellow Alert Codes
1 Flash Long run time
2 Flashs System pressure trip
3 Flashs Short cycling
4 Flashs Locked rotor
5 Flashs Open circuit
6 Flashs Open start circuit
7 Flashs Open run circuit
8 Flashs Welded Contactor
9 Flashs Low voltage
Planning Your Program – Important
The Heating and Cooling Program schedules below allow you
to pencil in your own program times and temperatures.
The 1F85-0422 comes configured for 5/1/1 day programming
and can also be configured for 5/2 day programming (see
configuration section).
Factory settings are listed on Monday through Friday, Satur-
day and Sunday. If you are re-programming a 5/2 day sched-
ule, pencil in your own times and temperatures directly below
the factory times and temperatures.
If you are re-programming a 5+1+1 fill in all lines with the
times and temperatures you want.
Keep the following guidelines in mind when planning your
program.
• InHeating,lowertemperatureswillsaveenergy.
• InCooling,highertemperatureswillsaveenergy.
• IfyouplanonusingAutoChangeover,donotprogram
the heating higher than the cooling.
Worksheet for Re-Programming 5/2 Day and 5+1+1 Day Program
Heating
Program
Wake Up
(Period 1)
Leave For Work
(Period 2)
Return Home
(Period 3)
Go To Bed
(Period 4)
Mon-Fri
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
Sat-Sun
or Sat
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
Sun
5+1+1 only
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
Cooling
Program
Wake Up
(Period 1)
Leave For Work
(Period 2)
Return Home
(Period 3)
Go To Bed
(Period 4)
Mon-Fri
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 78°F
Sat-Sun
or Sat
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 78°F
Sun
5+1+1 only
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 78°F
