Quick Start Guide
17
December 2016
North American and Canadian approvals
Factory Mutual (FM) explosion-proof approval
(See “Instructions for hazardous area installations (E5 and E6)” on page 18)
E5 Project ID: 3012658
Explosion-proof for Class I, Div. 1, Groups A, B, C, and D
Temperature Class: T6 (T
amb
–40 to 75 °C)
Enclosure: Type 4X
Factory Mutual (FM) intrinsically safe and non-incendive approvals
(See “Instructions for hazardous area installations (I5 and I6)” on page 20)
I5 Project ID: 3011456
Intrinsically safe for:
Class I, Div. 1, Groups A, B, C, and D; Class I, Zone 0, AEx ia IIC
Nonincendive for: Class I, Div. 2, Groups A, B, C and D; Class I, Zone 2, IIC
Temperature Code: T5 (T
amb
–40 to 80 °C, T
proc
< 80 °C)
Control Drawing: 71097/1154 (with NAMUR electronics)
Control Drawing: 71097/1314 (with 8/16 mA electronics)
Canadian Standards Association (CSA) explosion-proof approval
(See “Instructions for hazardous area installations (E5 and E6)” on page 18)
E6 Project ID: 1786345
Explosion-proof for Class I, Div. 1, Groups A, B, C, and D
Temperature Class: T6 (T
amb
–40 to 75 °C)
Enclosure: Type 4X
Single process seal
Canadian Standards Association (CSA)
intrinsically safe and non-incendive approvals
(See “Instructions for hazardous area installations (I5 and I6)” on page 20)
I6 Certificate Number: 06 CSA 1786345
Intrinsically safe for:
Class I, Div. 1, Groups A, B, C, and D; Class I, Zone 0, Ex ia IIC
Non-Incendive for: Class I, Div. 2, Groups A, B, C, and D
Temperature Code: T5 (T
amb
–40 to 80 °C, T
proc
< 80 °C)
Control Drawing: 71097/1179 (with NAMUR electronics)
Control Drawing: 71097/1315 (with 8/16 mA electronics)
Single process seal
European approvals
ATEX approvals
E1 Certificate: Sira 05ATEX1129X
Flameproof and dust-proof:
ATEX Marking II 1/2 GD
Ex db IIC T6...T2 Ga/Gb, Ex tb IIIC T85 °C...T265 °C Db
(See “Instructions for hazardous area installations (E1 and E7)” on page 22)
