10.17 Menu 20: Application menu 2
Table 10-30 Menu 20 parameters: single line descriptions
Menu 20 contains parameters that do not affect the operation of the drive. These general purpose parameters are only for use with fieldbus and drive
user programming. The read-write parameters in this menu cannot be saved in the drive.
Parameter Range Default Setting Update Rate
20.00 Not used
20.01 Not used
20.02 Not used
20.03 Not used
20.04 Not used
20.05 Not used
20.06 Not used
20.07 Not used
20.08 Not used
20.09 Not used
20.10 Not used
20.11 Not used
20.12 Not used
20.13 Not used
20.14 Not used
20.15 Not used
20.16 Not used
20.17 Not used
20.18 Not used
20.19 Not used
20.20 Not used
20.21 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.22 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.23 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.24 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.25 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.26 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.27 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.28 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.29 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.30 Application menu 2 read-write long integer
-2
31
to 2
31
-1
0
N/A
20.00 to 20.20 Unused parameters
20.21 to 20.30 Application menu 2 read-write long integer
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11
Range
-2
31
to 2
31
-1
Default 0
Update rate N/A
