10.7 Menu 6: Drive sequencer and clock
Table 10-8 Menu 6 parameters: single line descriptions
* Only available on Commander SK size B, C and D.
** On with USA defaults.
Parameter Range Default Setting Update Rate
6.01 Stop mode select {31} 0 to 4 1 2 ms
6.02 Not used
6.03 Mains loss mode diS(0), StoP(1), rd.th(2) diS(0) 2 ms
6.04 Start/stop logic select {11} 0 to 6
0 (Eur)
4 (USA)
Edit mode exit
6.05 Not used
6.06 Injection braking level 0.0 to 150.0% 100.0 B
6.07 Injection braking time 0.0 to 25.0 s 1.0 2 ms
6.08 Not used
6.09 Catch a spinning motor select {33} 0 to 3 0 B
6.10 Low DC bus operation* OFF(0) or On(1) OFF(0) B
6.11 Remote LED keypad function key status OFF(0) or On(1) OFF(0) B
6.12 Enable stop key OFF(0) or On(1) OFF(0)** B
6.13 Function key mode 0 to 6 0 BR
6.14 Disable auto reset on enable OFF(0) or On(1) OFF(1) 2 ms
6.15 Drive enable OFF(0) or On(1) On(1) 2 ms
6.16 Electricity cost per kWh 0.0 to 600.0 currency/kWh 0.0 B
6.17 Reset energy meter OFF(0) or On(1) OFF(0) B
6.18 Not used
6.19 Not used
6.20 Not used
6.21 Not used
6.22 Run time log: years.days 0.000 to 9.365 years.days B
6.23 Run time log: hours.minutes 0.00 to 23.59 hours.minutes
B
6.24 Energy meter: MWh 0.0 to 999.9 MWh
B
6.25 Energy meter: kWh 0.00 to 99.99 kWh
B
6.26 Running cost ±32000 currency/hour
B
6.27 Not used
6.28 Not used
6.29 Hardware enable OFF(0) or On(1) OFF(0) 2 ms
6.30 Sequencing bit: Run forward OFF(0) or On(1) OFF(0) 2 ms
6.31 Sequencing bit: Jog forward OFF(0) or On(1) OFF(0) 2 ms
6.32 Sequencing bit: Run reverse OFF(0) or On(1) OFF(0) 2 ms
6.33 Sequencing bit: Fwd/Rev OFF(0) or On(1) OFF(0) 2 ms
6.34 Sequencing bit: Run OFF(0) or On(1) OFF(0) 2 ms
6.35 Forward limit switch OFF(0) or On(1) OFF(0) 2 ms
6.36 Reverse limit switch OFF(0) or On(1) OFF(0) 2 ms
6.37 Sequencing bit: Jog reverse OFF(0) or On(1) OFF(0) 2 ms
6.38 Not used
6.39 Sequencing bit: /Stop OFF(0) or On(1) OFF(0) 2 ms
6.40 Enable sequencer latching OFF(0) or On(1) OFF(0) 2 ms
6.41 Not used
6.42 Control word 0 to 32767 0 2 ms
6.43 Control word enable OFF(0) or On(1) OFF(0) 2 ms
6.44 Not used
6.45 Force cooling fan to run at full speed OFF(0) or On(1) OFF(0) B
