Defines the destination parameter for the variable selector 2 output.
Indicates the level of output signal from the variable selector.
Can be used to scale the source 1 input of the variable selector.
Can be used to scale the source 2 input of the variable selector.
The control parameter can be used to input a value when modes 6, 7 and 9 of the variable selector are implemented. See Pr 12.10 on page 157 and
Pr 12.30 on page 159 for variable selector modes.
12.31 Variable selector 2 destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
12.32 Variable selector 2 output
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range ±100.0%
Update rate 21 ms
12.33 Variable selector 2 source 1 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range ±4.000
Default 1.000
Update rate 21 ms
12.34 Variable selector 2 source 2 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range ±4.000
Default 1.000
Update rate 21 ms
12.35 Variable selector 2 control
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 111
Range 0.00 to 99.99
Default 0.00
Update rate Background
12.36 to 12.39 Unused parameters
