Table 4-9: Acceleration Band 1 (continued)
Axis Severity Upper Limit Lower Limit Units Remarks
Acceleration
Band 1
Advise 4 0 g
Table 4-10: Acceleration Band 2
Axis Severity Upper Limit Lower Limit Units Remarks
Acceleration
Band 2
Saturated 100 0 g
Acceleration
Band 2
Sensor 100 0 g Acceleration
Band 2 Out of
Range
Acceleration
Band 2
Range 50 0 g
Acceleration
Band 2
Fail 15 0 g Acceleration
Band 2 Failure
Acceleration
Band 2
Maint 10 0 g Acceleration
Band 2
Maintenance
Acceleration
Band 2
Advise 6 0 g Acceleration
Band 2 Advise
Table 4-11: Machine Temperature
Axis Severity Upper Limit Lower Limit Units Remarks
Machine
Temperature
Saturated 95 -50 °C
Machine
Temperature
Sensor 95 -50 °C Machine Temp
Out of Range
Machine
Temperature
Range 95 -50 °C
Machine Temp Fail 75 -40 °C Machine Temp
Failure
Machine
Temperature
Maint 70 -35 °C Machine Temp
Maintenance
Machine
Temperature
Advise 65 -30 °C Machine Temp
Advise
Table 4-12: Supply Voltage
Axis Severity Upper Limit Lower Limit Units Remarks
Supply
Voltage
Saturated 3.75 0 V
