Emerson Bettis G4 Series Disassembly And Reassembly

October 2015
Service Instructions
127072E Rev. C
30
Section 5: Module Removal and Installation
Module Removal and Installation
NOTE:
The spherical side of washer (1-40) will be facing the outside of guide block (1-30).
5�8�4 Install second spherical washer (1-40) over threaded end of extension rod
assembly (1-50).
NOTE:
The spherical side of the washer will go on the extension rod assembly facing the head of
the extension rod assembly.
5�8�5 Install extension rod assembly (1-50) into right of guide block (1-30) and up
against the rst spherical washer (1-40).
5�8�6 Install extension retainer nut assembly (1-60) over extension rod assembly (1-50)
and screw into guide block (1-30).
5�8�7 Tighten extension retainer nut assembly (1-60) until extension rod assembly
(1-50) is immovable. Back off the extension retainer nut assembly (1-60) just
enough to allow for extension rod assembly (1-50) to move freely.
