Model No.
Key
No. Description CF945WB00 CF945HTW00 CF945AB00 CF945PW00
Hanger Ball Assembly, 761655-20 761655-12 761655-3 761655-22
Consisting of:
1 Hanger Bracket — — — —
2 Hanger Ball — — — —
3 Downrod — — — —
Parts Bag Containing: 762292 762292-1 762292 762292
4 Wire Connector (3) — — — —
5 Wrench, Hex , 5/64 — — — —
6 Threaded Stud (2) — — — —
7 Lockwasher (2) — — — —
8 Knurled Knob (2) — — — —
9 Pin, Clevis — — — —
10 Clip, Hairpin — — — —
11 Screw, 1/4-20 x 1/2” (11) — — — —
12 Screw, 3/16-24 x 3/8” (16) — — — —
13 Washer, Plastic (16) — — — —
14 Screw, 5/32-32 x 3/8” (3) — — — —
15 Ceiling Cover 761939-3 761939-1 761939-6 761939-7
16 Coupling Cover 761860-6 761860-5 761860-7 761860-12
17 Remote Control Transmitter 762281 762281 762281 762281
18 Switch Housing 762257 762257-1 762257-2 762257-3
19 Flange (Set of 5) 762288 762288-1 762288-2 762288-3
20 Blade (Set of 5) 761859-24 761859-6 761859-8 761859-17
21 Remote Control Receiver 762291 762291 762291 762291
22 Downrod, 18” 760239-146 760239-183 760239-40 760239-161
23 Rod Assembly (3) 762290 762290-1 762290-2 762290-3
24 Rod Support Assembly 762289 762289-1 762289-2 762289-3
—
Owner's Manual BP7265 BP7265 BP7265 BP7265
Before discarding packaging material, be certain all parts
have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWING INFORMATION:
• PART NUMBER • PART DESCRIPTION
• NAME OF ITEM • MODEL NUMBER
For repair parts, phone 1-800-654-3545.
Part No. F40BP72650000 Printed in Taiwan 03/02 Form No. BP7265
