Specifications
Eb-203
NT-212
12.5
(1.41)
27
(3.05)
0.8
(0.6)
0.000164
(0.185)
5000 2048 34.7
5.08
(0.57)
MG-205
5
(0.56)
15.0
(1.69)
0.31
(0.23)
0.000084
(0.95)
5000 2048 28.3
4.1
(0.46)
MG-208
9.1
(1.03)
20
(2.26)
0.58
(0.43)
0.000144
(0.163)
5000 2048 28.3
4.1
(0.46)
MG-316
15.8
(1.79)
31.8
(3.59)
1.0
(0.75)
0.000498
(0.562)
4000 2048 37.6
5.5
(0.62)
Eb-205
NT-212
12.5
(1.41)
27
(3.05)
0.8
(0.6)
0.000164
(0.185)
5000 2048 34.7
5.08
(0.57)
NT-320
19
(2.15)
30
(3.39)
1.02
(0.76)
0.000328
(0.3703)
4000 2048 29
3.5
(0.3955)
NT-330
26
(2.94)
44
(4.97)
1.43
(1.07)
0.000438
(0.4975)
4000 2048 36
5.04
(0.5695)
NT-345
38
(4.29)
66
(7.46)
1.71
(1.28)
0.000668
(0.7542)
3000 2048 50
7.13
(0.8056)
MG-205
5
(0.56)
15.0
(1.69)
0.31
(0.23)
0.000084
(0.95)
5000 2048 28.3
4.1
(0.46)
MG-208
9.1
(1.03)
20
(2.26)
0.58
(0.43)
0.000144
(0.163)
5000 2048 28.3
4.1
(0.46)
MG-316
15.8
(1.79)
31.8
(3.59)
1.0
(0.75)
0.000498
(0.562)
4000 2048 37.6
5.5
(0.62)
Drive Motor
Cont.
Torque
lb-in
(Nm)
Peak
Torque
lb-in
(Nm)
Power
HP @
Rated
Speed
(kWatts)
Inertia
lb-in-sec
2
(kg-cm
2
)
Max
speed
RPM
Encoder
resolution
lines/rev
Motor Ke
VRMS/
krpm
Motor Kt
lb-in/
ARMS
(Nm/
ARMS)
