49
Specifications
Fault Detection Capability
Low DC bus
High DC bus
Power Stage fault
Logic power
Encoder state
Encoder line break
Motor over temperature
Overspeed
Travel limit (+)
Travel limit (-)
Pulse mode position error
RMS shunt power fault
Function module error
Power-up self test failure
Non-volatile memory invalid
Environmental
Ambient temperature range
for rated output:
32° F to 104° F (0° C to 40° C)
Maximum Ambient operating
temperature:
32° F to 122° F (0° C to 50° C) with power derating of
3.5%/1.8° F (1° C) above 104° F (40° C)
Rated Altitude:
3,280 feet (1000 m)
Vibration:
10 - 2000 Hz at 2g
Humidity:
10 - 95% non-condensing
Storage Temperature:
-13° to 167° F (-25° to 75° C)
Ingress Protection (IP):
IP20
Standards and Agency Approvals
UL Listed
Canadian UL Listed
CE Mark: Low voltage directive; EMC directive
Cooling Method
EN-204, EN-208: Convection
EN-214: Integral fan
Serial Interface
RS-232 / RS-485
Internal RS-232 to RS-485 converter
Modbus protocol with 32 bit data extension
9600 or 19.2 k baud
Drive Weights
EN-204 6.4 lb (2.9 kg)
EN-208
7.7 lb (3.5 kg)
EN-214 8.9 lb (4.0 kg)
Accessory Specifications
ALP-130:
Input 115/230 VAC; Output 140 VDC, 30 W
ALP-430:
Input 115/230 VAC; Output 140 VDC, (4)x20 W
EN Drive Specifications
