Emerson Control Techniques EN Series Installation Manual

51
Specifications
Motor Brake Specifications
Motor Weights
Motor
Holding
Torque
lb-in
(Nm)
Added Inertia
lb-in-sec2
(kg-cm2)
Added
Weight
lb (kg)
Coil Voltage
(VDC)
Coil Current
(Amps)
Mechanical
Disengagement
Time
Mechanical
Engagement
Time
NTE/M-2XX
-CBNS, -LBNS,
-TBNS
20
(2.26)
0.000106
(0.12)
1
(0.46)
24 (±10%) 0.33 (±10%) 28 ms 14 ms
NTE/M-3XX
-CBNS, -LBNS,
-TBNS
88.5
(10)
0.000968
(1.093)
1
(0.46)
24 (±10%) 0.65 (±10%) 43 ms 13 ms
MGE-2XXCB
10
(1.13)
0.000025
(0.0282)
1.8
(0.55)
24 (±10%) 0.48 (±10%) 25 ms 40 ms
MGE-316CB
MGM-340CB
50
(5.6)
0.00015
(0.1693)
2.4
(1.1)
24 (±10%) 0.52 (±10%) 100 ms 250 ms
MGE/M-455CB
MG-490CB
MG-4120CB
220
(24.9)
0.000412
(0.4652)
5.8
(2.6)
24 (±10%) 0.88 (±10%) 100 ms 250 ms
Motor
Weight
lb (kg)
without Brake
Weight
lb (kg)
with Brake
NTE/M-207 3.0 (1.36) 4 (1.81)
NTE/M-212 4 (1.81) 5 (2.268)
NTE/M-320 6 (2.72) 8.55 (3.88)
NTE/M-330 7.3 (3.31) 9.85 (4.47)
NTE/M-345 10 (4.54) 12.55 (5.70)
NTE/M-355 12.3 (5.58) 14.85 (6.74)
MGE-205 3.0 (1.36) N/A
MGE-208 4.0 (1.8) 5.8 (2.6)
MGE-316 8.3 (3.8) 10.7 (4.9)
MGM-340 14.6 (6.6) 17.0 (7.7)
MGE/M-455 18.5 (8.4) 24.3 (11.0)
MGE/M-490 27.0 (12.3) 32.8 (14.9)
MGE/M-4120 38.0 (17.3) 43.8 (19.9)
