EN Drive Installation Manual
NTE-207 and 212 Brake Motors; English Face (NEMA 23 with 3/8 inch shaft)
Note
Mounting ears have clearance for #10 or M5 Allen head screw or .3125" or 8mm across
flats hex nut.
NTE-207, 212 -CBNS, TBNS and LBNS Mounting Dimensions
inches (mm))
A B C
D
Max
E F G
I
Max
J
Max
K
Min
L
Min
M
Min
207-CBNS
6.945
(176.40)
2.27
(57.66)
0.295
(7.49)
1.50
(38.100)
0.10
(2.54)
0.205
(5.21)
2.625
(5.21)
1.21
(30.73)
0.375
(9.525)
0.70
(17.78)
0.1248
(3.17)
0.075
(1.905)
207-
TBNS/
LBNS
6.277
(159.44)
2.27
(57.66)
0.295
(7.49)
1.50
(38.100)
0.10
(2.54)
2.05
(5.21)
2.625
(66.68)
1.210
(30.73)
0.375
(9.525)
0.70
(17.78)
1.498
(38.049)
0.075
(1.905)
212-CBNS
7.945
(201.80)
2.27
(57.66)
0.295
(7.49)
1.50
(38.100)
0.10
(2.54)
0.205
(5.21)
2.625
(66.68)
1.21
(30.73)
0.375
(9.525)
0.70
(17.78)
0.1248
(3.17)
0.075
(1.905)
212-
TBNS/
LBNS
7.277
(184.84)
2.27
(57.66)
0.295
(57.66)
1.50
(38.100)
0.10
(2.54)
0.205
(5.21)
2.625
(66.68)
1.210
(30.73)
0.375
(9.525)
0.70
(17.78)
0.1248
(3.17)
0.075
(1.905)
1.98 [50.39]
MAX
BRAKE CONN: PT02E-8-3P
MATING CONN: PT06E-8-3S (-CBNS)
ENCODER CONN: PT02E-16-23P
MATING CONN: PT06E-16-23S (-CBNS)
MOTOR CONN: PT02E-16-8P
MATING CONN: PT06E-16-8S (-CBNS)
A
J
FLYING LEAD LENGTH:
39.37±2.00 [1000±50.8]
(-LBNS and -TBNS)
J
ENCODER CONN: PT02E-16-23P
MATING CONN: PT06E-16-23S
(-TBNS)
BRAKE CONN: PT02E-8-3P
MATING CONN: PT06E-8-3S
(-TBNS)
MOTOR CONN: PT02E-16-8P
MATING CONN: PT06E-16-8S
(-TBNS)
