Physical Layout of the unit
Transport and Storage
Move F-Series unit only with appropriate mechanical or handling equipment according to weight.
Keep in the upright position. Do not stack single boxes on top of each other without pallet in any
case. Keep the packaging dry at all times.
Unit Lifting
If the unit is dropped, it should immediately be checked for damage.
Caution
The unit should be lifted from the base and where possible, with all packing and protection in
position.
1. Service valves for customer connection 2. Liquid receiver
3. Scroll compressor 4. HP/LP cutout 5. Junction box
1
1
2
3
4
5
7
