32
© 2016 Emerson Climate Technologies, Inc.
AE5-1412 R1
13. Parameters
Label Description Default Range
Default Display Value
Current Suction Pressure (PSIG)
Adjustable in Programming Menu
Compressor
Cin / Compressor cut in pressure set point (PSIG) 25.0 Cou - 135
CoU / Compressor cut out pressure set point (PSIG) 15.0 0 - Cin
rEF / Refrigerant Selection for Regulation R404A All unit Refs
Low Side Control
idF / interval between defrost cycles (hour) 8 0 - 120
MdF / Maximum length for defrost (min) 45 0 - 255
EdF / Defrost interval mode in nu, in, RTC
Ld1 / Workday defrost start 1 (hour) 6:00 nu, 0:00 - 23:50
Ld2 / Workday defrost start 2 (hour) 13:00 nu, 0:00 - 23:50
Ld3 / Workday defrost start 3 (hour) 21:00 nu, 0:00 - 23:50
Ld4 / Workday defrost start 4 (hour) nu nu, 0:00 - 23:50
Ld5 / Workday defrost start 5 (hour) nu nu, 0:00 - 23:50
Ld6 / Workday defrost start 6 (hour) nu nu, 0:00 - 23:50
Real Time Clock
Min / Current minute 0 - 59
Hr / Current hour 0 - 23
MdY / day of month 1 - 31
Mon / month 1 - 12
YEr / year 0 - 99
Password
PAS / Enter into PR2 level 321 (blank)
Adjustable from Advanced Options Menu
Probe Conguration
P1F / Probe P1 calibration (PSIG) 0.0 -12.0 - 12.0
Display
Lod / Remote Display visualization P1 P1 - P7
Compressor
LAS /
Ambient temperature required to initiate low
ambient on time (°F)
-20 -40 - 230
LMO / Low ambient minimum on time (sec) 6 0 - 255
